AIDA P1000T條碼列印機除了擁有自動偵測定紙功能外，列印快速，效能極佳，且此台熱感印表機Ticket Thermal Barcode Printer支援乙太網路介面卡，是極推薦的條碼標籤機。
- AIDA P1100T系列Ticket Thermal Barcode Printer擁有自動偵測定紙功能，此款條碼機支援絕大多數的標籤紙，如：間距、連續、黑標、打孔等。
- AIDA P1100T系列標籤印表機支援乙太網路及無線傳輸列印(選配)。
- AIDA P1100T系列商業型條碼標籤機 Barcode Label Printer支援圖形、向量字體、Unicode等各種內容列印。
- 此款條碼列印機列印速度最高178mm/秒。
- 此款熱感印表機支援300米長度碳帶，無需頻繁更換。
- 此款條碼標籤機可列印6mm最小高度標籤。
- 此款條碼機可檢測空白標籤並自動跳印，資料不遺失。
- 熱轉及熱感二用的桌上型條碼標籤機。
產品規格
| P1128T | P1138T | |
|---|---|---|
| 列印模式 | Thermal Transfer, Direct Thermal | Thermal Transfer, Direct Thermal |
| 列印寬度 | Max. 108mm | Max. 105.7mm |
| 列印速度 | Max. 178mm/s, 7ips | Max. 127mm/s, 5ips |
| 解析度 | 203dpi | 300dpi |
| 紙捲寬度 | 110mm | 110mm |
| 介面 | Type：onboard 1.Serial + Parallel +USB V2.0HS 2.Serial + Ethernet/WLAN +USB V2.0HS | Type：onboard 1.Serial + Parallel +USB V2.0HS 2.Serial + Ethernet/WLAN +USB V2.0HS |
| 感測器 | GAP, Black Mark, Cover Open | GAP, Black Mark, Cover Open |
| 記憶體 | Flash:128MB RAM:64MB DDR2 | Flash:128MB RAM:64MB DDR2 |
| 條碼類型 | 1D:Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, RSS-14(limited, truncated, stacked), Standard 2-of-5, UPC-A, UPC-A and Upc-E with EAN 2or 5 digit extensions, UPC-E, Code 128 with subsets A/B/C, UCC/EAN-128, UPC-A with 2or 5 digit extensions, UPC-A and UPC-E with 2 or 5 digit extensions, EAN-8 and EAN-13, Japanese Postnet, MSI-3,German Post Code. 2D:Codablock, Code49, DataMatrix, Maxicode,Micro PDF417, PDF417, QRCode, RSS/GS1 DataBar Family, Aztec | 1D:Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, RSS-14(limited, truncated, stacked), Standard 2-of-5, UPC-A, UPC-A and Upc-E with EAN 2or 5 digit extensions, UPC-E, Code 128 with subsets A/B/C, UCC/EAN-128, UPC-A with 2or 5 digit extensions, UPC-A and UPC-E with 2 or 5 digit extensions, EAN-8 and EAN-13, Japanese Postnet, MSI-3,German Post Code. 2D:Codablock, Code49, DataMatrix, Maxicode,Micro PDF417, PDF417, QRCode, RSS/GS1 DataBar Family, Aztec |
| 支援語系 | SLCS, BPL-Z TM , BPL-E TM | 1D:Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, RSS-14(limited, truncated, stacked), Standard 2-of-5, UPC-A, UPC-A and Upc-E with EAN 2or 5 digit extensions, UPC-E, Code 128 with subsets A/B/C, UCC/EAN-128, UPC-A with 2or 5 digit extensions, UPC-A and UPC-E with 2 or 5 digit extensions, EAN-8 and EAN-13, Japanese Postnet, MSI-3,German Post Code. 2D:Codablock, Code49, DataMatrix, Maxicode,Micro PDF417, PDF417, QRCode, RSS/GS1 DataBar Family, Aztec |
| 電源 | VDC/A:24V / 2.5A | VDC/A:24V / 2.5A |
| 重量 | 2.8Kg | 2.8Kg |
| 尺寸 | 214 x 310 x 195 mm | 214 x 310 x 195 mm |
| 操作溫度 | 5℃~ 40℃ | 5℃ ~ 40℃ |
| 存儲溫度 | -20℃ ~ 60℃ | -20℃ ~ 60℃ |
